Technical Specifications

AttributeValue
Terminal Type5-Pin M12 Connector
Supply Voltage24 V
Output Type2 PNP
ManufacturerSick
Features
SeriesdeTec2 Core
Product Range
Response Time Max11 ms
BrandSick
Protective Area Height900 mm
Sensing Distance Max12000 mm
Beam Resolution30 mm
Height30.7
Protection TypeBody, Hand
Range
PL (EN ISO 13849-1)PL c
Length913
Maximum Protective Width
Sensing Distance Min0 mm
Component TypeReceiver
Dimensions913 x 34 x 30.7 mm
Width34
Scanning Range
Safety Type2
SIL (IEC 61508)SIL 1
