Technical Reference

Technical Specifications

AttributeValue
Standards MetCE Marked, cULus Recognized
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Thread SizeM8
Terminal Type3-Pin M8 Male Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeRetroreflective
Switching ModeDark Switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range6000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable with Connector
Dimensions
Length21 mm
Width12 mm
Height31.5 mm
SeriesG6
