Technical Reference

Technical Specifications

Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP66 - dust tight; heavy seas protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature60 °C
Reverse Polarity Protection
Output TypeNPN
Standards MetUL Certified, CE Marked
Thread Size
Terminal Type4-Wire 2 m Cable
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Material DetectedPlastic - Transparent, Glass - Transparent
Detection TypeRetroreflective
Switching ModeDark Switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range5000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable
Dimensions12.2 x 41.8 x 17.3 mm
Width12.2 mm
Height41.8 mm
SeriesW4S-3 Glass
