Technical Reference

Technical Specifications

AttributeValue
Thread Size
Terminal Type
Mounting TypePanel Mount
Housing MaterialPlastic
Body StyleRectangular
Standards MetCE Marked
Sensor TechnologyPhotoelectric
IP RatingIP66 - dust tight; heavy seas protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeElectrically Isolated Relay
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeDiffuse
Switching ModeLight/Dark switching
Light SourceInfrared
Hazardous Area Certification
Maximum Detection Range380 mm
Minimum Detection Range0 mm
Maximum AC Supply Voltage240 V
Minimum AC Supply Voltage24 V
Maximum DC Supply Voltage240 V
Minimum DC Supply Voltage12 V
Electrical ConnectionCable Gland
Dimensions25 x 77.8 x 63 mm
Length63 mm
Width25 mm
Height77.8 mm
SeriesW260
