Technical Reference

Technical Specifications

AttributeValue
Output TypePNP
Maximum Operating Temperature55
Maximum DC Voltage30 V
Minimum Operating Temperature-25
IP RatingIP67
Detection Range15000 mm
Standards Met
Mounting Type
Thread Size
Terminal Type
Housing MaterialMetal
Body StyleCylindrical
ManufacturerSick
Optical Technology
Detection TypeThrough Beam
SeriesGR18S
Sensor TypeCylindrical
Light SourcePolarized Red Light
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time0.5 ms
Electrical ConnectionM12 Connector
