Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature60 °C
ShieldingN/A
Reverse Polarity Protection
Output TypeElectrically Isolated Relay
Thread Size
Terminal Type3-Wire 2 m Cable
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Standards MetCE Marked, cULus Recognized
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeThrough Beam
Switching Mode
Light SourcePolarized
Hazardous Area Certification
Maximum Detection Range40000 mm
Minimum Detection Range0 mm
Maximum AC Supply Voltage240 V
Minimum AC Supply Voltage24 V
Maximum DC Supply Voltage240 V
Minimum DC Supply Voltage24 V
Electrical ConnectionCable
Dimensions
Length51.5 mm
Width20 mm
Height50 mm
SeriesG10
