Technical Reference

Technical Specifications

AttributeValue
Thread Size
Terminal Type4-Pin M12 Connector
Mounting Type
Housing MaterialStainless Steel
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Standards MetcULus Listed, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeThrough Beam
Switching ModeLight/Dark switching
Light SourcePolarized
Hazardous Area Certification
Maximum Detection Range14500 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions
Length22 mm
Width15 mm
Height44 mm
SeriesG6 Inox
