Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature60 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP/NPN
Thread SizeM12
Terminal Type4-Pin M12 Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeBackground Suppression
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range900 mm
Minimum Detection Range60 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions
Length48.9 mm
Width20.6 mm
Height99.2 mm
SeriesZoneControl
