Technical Reference

Technical Specifications

AttributeValue
Standards MetCE Marked
Thread SizeM12
Terminal Type4-Pin M12 Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP66 - dust tight; heavy seas protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeThrough Beam
Switching ModeLight/Dark switching
Light SourcePolarized
Hazardous Area Certification
Maximum Detection Range60000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions23.5 x 74.5 x 63 mm
Length63 mm
Width23.5 mm
Height74.5 mm
SeriesW280-2
