Technical Reference

Technical Specifications

AttributeValue
Standards MetECOLAB Certified, UL Certified, CE Marked
Sensor TechnologyPhotoelectric
IP RatingIP68 - dust tight; water submersion protected, IP67 - dust tight; water immersion protected, IP66 - dust tight; heavy seas protected, IP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature70 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Thread SizeM8
Terminal Type3-Pin M8 Connector
Mounting Type
Housing MaterialStainless Steel
Body StyleRectangular
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeThrough Beam
Switching ModeLight Switching
Light SourcePolarized
Hazardous Area Certification
Maximum Detection Range5000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions15.25 x 44.5 x 22.2 mm
Length22.2 mm
Width15.25 mm
Height44.5 mm
SeriesW4S-3 Inox
