| Thread Size | M8 |
| Terminal Type | 4-Pin M8 Connector |
| Mounting Type | |
| Housing Material | Plastic |
| Body Style | Rectangular |
| Standards Met | UL Certified, CE Marked |
| Sensor Technology | Photoelectric |
| IP Rating | IP67 - dust tight; water immersion protected, IP66 - dust tight; heavy seas protected, IP69K - dust tight; close-range high-pressure hot water protected |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | 60 °C |
| Shielding | N/A |
| Reverse Polarity Protection | |
| Output Type | PNP |
| Material Detected | Metal, Plastic - Opaque, Glass - Opaque |
| Brand | Sick |
| Detection Type | Background Suppression |
| Switching Mode | Light/Dark switching |
| Light Source | Infrared |
| Hazardous Area Certification | |
| Maximum Detection Range | 500 mm |
| Minimum Detection Range | 20 mm |
| Maximum DC Supply Voltage | 30 V |
| Minimum DC Supply Voltage | 10 V |
| Electrical Connection | Connector |
| Dimensions | 12.2 x 49.8 x 23.6 mm |
| Length | 23.6 mm |
| Width | 12.2 mm |
| Height | 49.8 mm |
| Series | W9 |
