Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyPhotoelectric
IP RatingIP69 - dust tight; high-pressure hot water protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature60 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP/NPN
Thread SizeM12
Terminal Type4-Pin M12 Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeBackground Suppression
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range500 mm
Minimum Detection Range10 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions20 x 55.7 x 42 mm
Length42 mm
Width20 mm
Height55.7 mm
SeriesW16
