Technical Reference

Technical Specifications

Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature50 °C
Reverse Polarity Protection
Output TypePNP/NPN
Thread SizeM12
Terminal Type5-Pin M12 Cable
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
Detection TypeBackground Suppression
Switching ModeLight/Dark switching
Light SourceLaser
Hazardous Area Certification
Maximum Detection Range3000 mm
Minimum Detection Range200 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionCable with Plug
Dimensions17.4 x 45.6 x 34.7 mm
Length34.7 mm
Width17.4 mm
Height45.6 mm
