Technical Reference

Technical Specifications

AttributeValue
Thread SizeM8
Terminal Type4-Pin M8 Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-10 °C
Maximum Operating Temperature50 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Standards MetUL Certified, CE Marked
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeBackground Suppression
Switching ModeLight/Dark switching
Light SourceLaser
Hazardous Area Certification
Maximum Detection Range2500 mm
Minimum Detection Range200 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions17.6 x 46.5 x 34.1 mm
Length34.1 mm
Width17.6 mm
Height46.5 mm
SeriesPowerProx
