Technical Reference

Technical Specifications

AttributeValue
Mounting TypeThreaded
Housing MaterialStainless Steel/Plastic
Supply Voltage15 V dc - 35 V dc
Output Type4 - 20 mA
Maximum Operating Temperature85
Minimum Operating Temperature-20
IP RatingIP67
ManufacturerSick
SeriesPBS Plus
Media MonitoredWater, Liquid, Oil, Hydraulic Fluid, Gas, Air
Maximum Pressure Reading10 bar
Hazardous Area Certification
Calibrated
BrandSick
Accuracy %±0.5%
Communication InterfaceIO-LINK
Response Time5 ms
Process ConnectionG 1/4
Pressure TypeRelative
For Use With
Maximum Switching Current600 mA
Pressure Reading Min0 bar
Electrical ConnectionM12 Connector
