Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-15 °C
Maximum Operating Temperature55 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Standards MetUL Certified
Thread SizeM12
Terminal Type4-Pin M12 Connector
Mounting Type
Housing MaterialPlastic
Body StyleBarrel
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeRetroreflective
Switching ModeDark Switching
Light SourceLaser
Hazardous Area Certification
Maximum Detection Range35000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions18 x 18 x 107.7 mm
SeriesV18 Laser
