Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Thread Size
Terminal Type4-Wire Cable
Mounting TypeFlush
Housing MaterialPlastic
Body StyleRectangular
Sensor TechnologyCapacitive
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-20 °C
Maximum Operating Temperature75 °C
ShieldingShielded
Reverse Polarity ProtectionYes
Output TypePNP
Standards MetUL Certified, CE Marked
Material DetectedMetal
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range8 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Maximum AC output current150 mA
Electrical ConnectionCable
Dimensions12 x 36.5 x 16 mm
Length12 mm
Depth36.5 mm
Height16 mm
SeriesCQ
