Technical Reference

Technical Specifications

AttributeValue
Thread SizeM8
Terminal Type3-Pin M8 Connector
Mounting TypePanel Mount
Housing MaterialStainless Steel
Body StyleRectangular
Standards MetUL Certified, CE Marked
Sensor TechnologyPhotoelectric
IP RatingIP69K - dust tight; close-range high-pressure hot water protected
Minimum Operating Temperature-30 °C
Maximum Operating Temperature70 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Material DetectedMetal, Plastic - Opaque, Glass - Opaque
BrandSick
Detection TypeDiffuse
Switching ModeLight Switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range500 mm
Minimum Detection Range3 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions15.25 x 44.9 x 22.2 mm
Length22.2 mm
Width15.25 mm
Height44.9 mm
SeriesW4S-3 INOX
