Technical Reference

Technical Specifications

AttributeValue
Standards Met
Output TypeNO/NC
Maximum Operating Temperature60
Maximum DC Voltage240 V
Minimum Operating Temperature-40
IP RatingIP67
Detection Range22000 mm
Mounting TypePanel Mount
Thread Size
Terminal Type5 Terminal Screw
Housing MaterialABS
Body StyleRectangular
ManufacturerSick
Optical TechnologyPhototransistor
Detection TypeRetro-reflective
SeriesW34
Sensor TypeBlock
Maximum AC Voltage240 V
Light SourceInfrared LED
Maximum Current4000 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time10 ms
Electrical Connection5 Terminal Screw
