Technical Reference

Technical Specifications

Output TypePNP
Maximum Operating Temperature60
Maximum DC Voltage30 V
Minimum Operating Temperature-40
IP RatingIP66, IP67
Detection Range4500 mm
Mounting TypePanel Mount
Thread Size
Terminal TypeConnector M8 - 4 Pin
Housing MaterialABS
Body StyleRectangular
Standards MetCE, cULus, ECOLAB
Optical TechnologyPhotoelectric
Detection TypeRetro-reflective
SeriesW4-3 Glass
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current20 mA
Hazardous Area Certification
Switching Mode
Communication InterfaceIO-Link
Response Time0.5 ms
Electrical ConnectionM8 4 Pin Connector
