Technical Reference

Technical Specifications

AttributeValue
Output TypePNP
Maximum Operating Temperature60 °C
Maximum DC Voltage30 V
Minimum Operating Temperature-30 °C
IP RatingIP67
Detection Range12000 mm
Standards Met
Mounting Type
Thread Size
Terminal TypeCable with connector
Housing MaterialPlastic
Body StyleRectangular
ManufacturerSick
Optical Technology
Detection TypeRetro-reflective
SeriesG10
Sensor TypeBlock
Light SourcePinPoint LED
Maximum Current
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time0.5 ms
Electrical ConnectionCable with connector
