Technical Reference

Technical Specifications

AttributeValue
Standards MetUL Certified, CE Marked
Thread SizeM12
Terminal Type5-Pin M12 Connector
Mounting Type
Housing MaterialMetal
Body StyleRectangular
Sensor TechnologyPhotoelectric
IP RatingIP67 - dust tight; water immersion protected, IP66 - dust tight; heavy seas protected
Minimum Operating Temperature-40 °C
Maximum Operating Temperature60 °C
ShieldingN/A
Reverse Polarity Protection
Output TypePNP
Material DetectedPlastic - Transparent, Glass - Transparent
BrandSick
Detection TypeRetroreflective
Switching ModeLight/Dark switching
Light SourceLED
Hazardous Area Certification
Maximum Detection Range4000 mm
Minimum Detection Range0 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage10 V
Electrical ConnectionConnector
Dimensions15.5 x 48.5 x 42 mm
Length42 mm
Width15.5 mm
Height48.5 mm
SeriesW12G
