Technical Reference

Technical Specifications

Standards MetCE Marked, EAC Certified
Sensor TechnologyUltrasonic
IP RatingIP65 - dust tight; water jet protected, IP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature70 °C
Reverse Polarity ProtectionYes
Output TypePNP
Thread SizeM8
Terminal Type3-Pin M8 Male Connector
Mounting Type
Housing MaterialPlastic
Body StyleRectangular
Material Detected
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range150 mm
Minimum Detection Range13 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage15 V
Maximum AC output current200 mA
Electrical ConnectionConnector
Dimensions16 x 40.1 x 16.7 mm
Length16 mm
Depth40.1 mm
Height16.7 mm
