Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 30 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyUltrasonic
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
Mounting Type
Thread SizeM18 x 1
Terminal TypeAxial Plug
Housing MaterialPlastic
Body StyleCylindrical
ManufacturerSick
Shape
SeriesUM18
Depth18
Hazardous Area Certification
Standards/Approvals
BrandSick
Supply Voltage DC Max30 V
Application
Communication Interface
Sensing Distance350 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length52.7
Switching Frequency Max0.012 kHz
Dimensions52.7 x 18 x 18 mm
Width18
Electrical ConnectionAxial Plug
