Technical Reference

Technical Specifications

AttributeValue
Sensor TechnologyUltrasonic
IP RatingIP67 - dust tight; water immersion protected
Minimum Operating Temperature-25 °C
Maximum Operating Temperature70 °C
ShieldingN/A
Reverse Polarity ProtectionYes
Output TypeCurrent/Voltage
Standards MetUL Certified, CE Marked, EAC Certified
Thread SizeM30
Terminal Type5-Pin M12 Connector
Mounting Type
Housing MaterialNickel-Plated Brass
Body StyleBarrel
Material Detected
BrandSick
Detection Type
Switching Mode
Light Source
Hazardous Area Certification
Maximum Detection Range350 mm
Minimum Detection Range60 mm
Maximum DC Supply Voltage30 V
Minimum DC Supply Voltage9 V
Maximum AC output current200 mA
Electrical ConnectionConnector
DimensionsM30 x 84 mm
Length84 mm
Depth84 mm
SeriesUM30
