Technical Specifications

AttributeValue
Mounting TypePanel Mount
Thread Size
Terminal TypeM12 Connector
Housing MaterialVistal, Plastic
Body StyleRectangular
Output TypeNPN/PNP
Maximum Operating Temperature60 °C
Maximum DC Voltage30 V
Minimum Operating Temperature-40 °C
IP RatingIP66, IP67
Detection Range
Standards MetUL NRKH.E181493, UL NRKH7.E181493, CE Certified, cULus Recognized
ManufacturerSick
Optical Technology
Detection TypeRetro-reflective
SeriesW16
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time0.5 ms
Electrical ConnectionM12 Connector
