Technical Reference

Technical Specifications

AttributeValue
Output TypeNPN/PNP
Maximum Operating Temperature60
Maximum DC Voltage30 V
Minimum Operating Temperature-40
IP RatingIP66, IP67
Detection Range1600 mm
Mounting TypePanel Mount
Thread Size
Terminal TypeM12 Connector
Housing MaterialVistal, Plastic
Body StyleRectangular
Standards MetUL NRKH7.E181493, UL NRKH.E181493, CE Certified, cULus Recognized
ManufacturerSick
Optical Technology
Detection TypeRetro-reflective
SeriesW26
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time0.5 ms
Electrical ConnectionM12 Connector
