Technical Specifications

AttributeValue
Output TypePNP
Maximum Operating Temperature60 °C
Maximum DC Voltage30 V
Minimum Operating Temperature-40 °C
IP RatingIP66, IP69K, IP67
Detection Range
Mounting TypePanel Mount
Thread Size
Terminal TypeConnector M8 - 4 Pin
Housing MaterialVistal, Plastic
Body StyleRectangular
Standards MetUL NRKH.E181493, CE Certified, cULus Recognized
ManufacturerSick
Optical Technology
Detection TypeRetro-reflective
SeriesW9-3
Sensor TypeBlock
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time0.33 ms
Electrical ConnectionM8 4 Pin Connector
