Technical Specifications

AttributeValue
Mounting TypePanel Mount
Thread Size
Terminal TypeM12 Connector
Housing MaterialVistal, Plastic
Body StyleRectangular
Standards MetUL NRKH.E181493, CE Certified, cULus Recognized
Output TypeNPN/PNP
Maximum Operating Temperature50 °C
Maximum DC Voltage30 V
Minimum Operating Temperature-35 °C
IP RatingIP67
Detection Range3800 mm
ManufacturerSick
Optical Technology
Detection TypeRetro-reflective
SeriesPowerProx
Sensor TypeBlock
Light SourceLaser Light
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandSick
Communication Interface
Response Time5 ms
Electrical ConnectionM12 Connector
