| Built-in Signal Generator | No |
| Power Source | Mains |
| Oscilloscope Type | Mixed Signal |
| Input Impedance | 1 MΩ |
| Sample Rate | 2.5 GS/s |
| Display Type | TFT LCD |
| Calibrated service type | |
| Record Length | 10 Mpts |
| Maximum Vertical Sensitivity | 10000 (mV/div) |
| Dimensions | 370 x 148.6 x 252 mm |
| Number of Automatic measurements | 30 |
| Brand | Tektronix |
| Trigger Type | , Set Up & Hold, Pulse Width, Rise/Fall Time, Sequence, Time Out, Edge, Runt |
| Number of Channels | 16 |
| Memory Depth | 10 Mpts |
| Battery Type | |
| Wi-Fi | No |
| Waveform Refresh Rate | 280.000 wfm/s |
| Safety Category | 2011/65/EU and 2015/877 |
| Maximum Time Base | 1000 (s/div) |
| Digital/Analogue | Digital |
| Rise Time | 4 ns |
| Minimum Time Base | 1 (ns/div) |
| Manufacturer | Tektronix |
| Number of Analogue Channels | 4 |
| Screen Size | 11.6 in |
| Weight | 5.3 kg |
| Bandwidth | 100 MHz |
| Minimum Vertical Sensitivity | 1 (mV/div) |
| Manufacturer Part Number | MDO34 3-BW-100 |
| Waveform Math and Analysis | Add, and Divide waveforms, Multiply, Subtract |
| Touch Screen | No |
| USB Powered | No |
| Input Capacitance | 3.9 pF |
| Vertical Resolution | 8 bit |
| Oscilloscope Form | Bench |
| Number of Digital Channels | 16 |
| Built-in Wave Generator | Yes |
| Communication Interface | LIN, CAN, IIC, USB, RS422, UART, RS232, RS485, SPI |
