Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Terminal Type
Supply Voltage24 V
Output TypePNP, 2 OSSD
ManufacturerTelemecanique
Number of Beams2
FeaturesAutomatic/Manual Restart, 2 PNP Output, Multi-Colour LEDs
SeriesXUSL2E
Product RangePreventa
Response Time Max3 ms
BrandTelemecanique
Protective Area Height510 mm
Sensing Distance Max12000 mm
Beam Resolution500 mm
Height653
Protection TypeBody
Range
PL (EN ISO 13849-1)PL c
Length31
Maximum Protective Width
Sensing Distance Min0 mm
Component TypeSender, Receiver
Dimensions31 x 29.4 x 653 mm
Width29.4
Scanning Range
Safety Type2
SIL (IEC 61508)SIL 1
