Technical Reference

Technical Specifications

AttributeValue
Mounting TypePanel Mount
Housing MaterialGlass Fibre Reinforced Polycarbonate
Supply Voltage240 V ac/250 V dc
Output Type1 C/O
Maximum Operating Temperature70
Minimum Operating Temperature-25
IP RatingIP54
ManufacturerTelemecanique Sensors
Series
Media MonitoredSea Water, Fresh Water, Air
Maximum Pressure Reading250 bar
Hazardous Area Certification
Calibrated
BrandTelemecanique Sensors
Accuracy %0.035
Communication Interface
Response Time
Process ConnectionG 1/4
Pressure TypeDifferential
For Use With
Maximum Switching Current100 mA
Pressure Reading Min3.5 bar
Electrical ConnectionScrew Clamp Terminal
