Technical Specifications

AttributeValue
Mounting Type
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPlastic
Body StyleCylindrical
Supply Voltage24 - 240 Vac
Output Type
Maximum Operating Temperature60
Sensor TechnologyCapacitive
ShieldingUnshielded
Minimum Operating Temperature-10
IP RatingIP67
Reverse Polarity ProtectionNo
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC240 V
Hazardous Area Certification
Standards/ApprovalscULus Certificate, EN, IEC 60947-5-2
BrandTelemecanique Sensors
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency25 Hz
Switching Current300 mA
Short Circuit Overload Protection
Length78
Switching Frequency Max
Dimensions
Width24
Electrical Connection4-Pin M12 Connector
