Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage12 V to 24 V
Output TypePNP
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP68
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPBT, Plastic
Body StyleRectangular
ManufacturerTelemecanique Sensors
Shape
Series
Depth32 mm
Hazardous Area Certification
Standards/ApprovalsC-Tick Certificate, IEC 60068-2-6, IEC 60529, UL Certificate, IEC 60068-2-27, CSA Certificate
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length15 mm
Switching Frequency Max2 kHz
Dimensions15 x 8 x 32 mm
Width8 mm
Electrical Connection4-Pin M12 Connector
