Technical Specifications

AttributeValue
Mounting Type
Thread Size
Terminal TypeCable
Housing MaterialPlastic
Body StyleRectangular
Supply Voltage12 V to 24 V
Output TypePNP NO
Maximum Operating Temperature65
Sensor TechnologyUltrasonic
Shielding
Minimum Operating Temperature-20
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
SeriesOsiSense XX
Depth60
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max24 V
Application
Communication Interface
Sensing Distance500 mm
Transducer Frequency
Accessory Type
For Use With
Switching FrequencyLess than or equal to 40 Hz
Switching Current100 mA
Short Circuit Overload Protection
Length44
Switching Frequency Max0.04 kHz
Dimensions44 x 18 x 60 mm
Width18
Electrical ConnectionCable
