Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type2m Cable, 2-Wire
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
Supply Voltage10 V to 58 V / 12 V to 48 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length63.5
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection2-Wire, 2 m Cable
