Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage10 V to 58 V / 12 V to 48 V
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM8 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialStainless Steel (Enclosure), PPS (Front)
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance2.5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length50.2
Switching Frequency Max3 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
