Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal Type2m Cable, 3-Wire
Housing MaterialStainless Steel (Enclosure), PPS (Front)
Body StyleCylindrical
Supply Voltage10 V to 38 V / 12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max38 V
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length64.3
Switching Frequency Max1 kHz
Dimensions
Electrical Connection3-Wire, 2 m Cable
