Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type2m Cable, 3-Wire
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
Supply Voltage20 V to 264 Vac/dc / 24 V to 210 V / 24 V to 240 Vac
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP67
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC264 V
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, CCC
BrandTelemecanique Sensors
Supply Voltage DC Max264 V
Application
Communication Interface
Sensing Distance10 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload ProtectionYes
Length61.9 mm
Switching Frequency Max2 kHz
Dimensions
Electrical Connection3-Wire, 2 m Cable
