Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V / 12 V to 24 V
Output TypeNPN
Maximum Operating Temperature50
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type2m Cable, 2-Wire
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length55
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection2-Wire, 2 m Cable
