Technical Specifications

AttributeValue
Supply Voltage10 V to 58 V / 12 V to 48 V
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM30 x 1.5
Terminal Type2m Cable, 3-Wire
Housing MaterialPPS
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CCC, CE
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length61.9
Switching Frequency Max1 kHz
Dimensions
Electrical Connection3-Wire, 2 m Cable
