Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V / 12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance2.5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length33.2
Switching Frequency Max2.5 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
