Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPPS
Body StyleRectangular
Supply Voltage12 V to 24 V
Output Type
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Depth32 mm
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance5 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length15 mm
Switching Frequency Max5 kHz
Dimensions15 x 8 x 32 mm
Width8 mm
Electrical Connection3-Pin M8 Connector
