Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPPS
Body StyleRectangular
Supply Voltage15 V to 36 V
Output TypeAnalogue
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP65, IP69K, IP67
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Depth131 mm
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, CCC
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance25 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current4 mA
Short Circuit Overload Protection
Length40 mm
Switching Frequency Max
Dimensions40 x 40 x 131 mm
Width40 mm
Electrical Connection3-Pin M8 Connector
