Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V / 12 V to 24 V
Output TypePNP
Maximum Operating Temperature70 °C
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25 °C
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPPS
Body StyleRectangular
ManufacturerTelemecanique Sensors
Shape
Series
Depth131 mm
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, CCC
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance20 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length40 mm
Switching Frequency Max0.25 kHz
Dimensions40 x 40 x 131 mm
Width40 mm
Electrical Connection4-Pin M12 Connector
