Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread Size
Terminal Type2m Cable, 3-Wire
Housing MaterialPPS
Body StyleRectangular
Supply Voltage10 V to 36 V / 12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Depth40
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance25 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length40
Switching Frequency Max1 kHz
Dimensions40 x 15 x 40 mm
Width15
Electrical Connection3-Wire, 2 m Cable
