Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V / 12 V to 24 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP69K, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread Size
Terminal Type3-Pin M8 Connector
Housing MaterialPPS
Body StyleRectangular
ManufacturerTelemecanique Sensors
Shape
Series
Depth72.9
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length40
Switching Frequency Max0.3 kHz
Dimensions40 x 40 x 72.9 mm
Width40
Electrical Connection3-Pin M8 Connector
