Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM18 x 1
Terminal Type4-Pin M12 Connector
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
Supply Voltage10 V to 58 V / 12 V to 48 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE, E2
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance8 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current200 mA
Short Circuit Overload ProtectionYes
Length62
Switching Frequency Max1 kHz
Dimensions
Electrical Connection4-Pin M12 Connector
