Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V / 12 V to 24 V
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type2m Cable, 3-Wire
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance2 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current100 mA
Short Circuit Overload ProtectionYes
Length37
Switching Frequency Max4 kHz
Dimensions
Electrical Connection3-Wire, 2 m Cable
