Technical Reference

Technical Specifications

AttributeValue
Supply Voltage20 V to 264 Vac/dc / 24 V to 240 Vac/dc
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity Protection
Mounting TypeFlush
Thread SizeM30 x 1.5
Terminal Type2m Cable, 2-Wire
Housing MaterialPPS, Nickel Plated Brass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Supply Voltage AC264 V
Hazardous Area Certification
Standards/ApprovalsCSA, UL Certified, CE
BrandTelemecanique Sensors
Supply Voltage DC Max264 V
Application
Communication Interface
Sensing Distance15 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current300 mA
Short Circuit Overload Protection
Length53.75
Switching Frequency Max0.5 kHz
Dimensions
Electrical Connection2-Wire, 2 m Cable
